SUPAIR LEAF 2
LEAF 2
FUN AND
SAFETY
On-site, thermal, mountain/seaside flying. With enhanced durability and greater precision than the LEAF, flying our LEAF 2 glider will quickly become second nature.
Category : EN-B
Sizes : XS / S / M / M-L / L
Coulours : Earth / Volcano / Canari
LEAF 2
For our R&D team, high quality finishes, ergonomic design and user-friendliness were keywords throughout the development process.
Thanks to feedbacks from resellers, pilots and instructors, we had great insights that helped us develop a glider with more easy-going take-off characteristics compared to the first generation LEAF. The inflation is gradual with great steadiness and stability. Handling is firm & progressive while passive safety has been optimised.
The LEAF 2 is fairly easy to handle, from the slight pitch when entering a thermal to the optimal roll angle when turning, you will master your LEAF 2 in no less than a day ! Ceiling, thermals, speed range, you comprehended and grasped every part and are now ready for the next flight : even higher and further.
INSIGHTS :
“Usually flying under EN-D gliders, I was not expecting such perforamnce from the LEAF 2. I experienced several enjoyable flights in vernal weather conditions.
I would describe the LEAF 2 as easy-to-use, efficient, safe and very pleasant. During take-off, the glider inflates gradually and uniformly. The simplified line layout reduces the probability of cravattes.
Flying the LEAF2 becomes very instinctive and the glider responds very well and with great precision. The large brake travel allows greater room for manoeuvre before flyiing out of the take-off site. In my opinion, it is a significant advantage that allows pilots to land back on the take-off site at low-speed or control the glider in turbulent situations for example.”
JULIEN HUGUES-DIT-CILES, EXPERIENCED XC PILOT
TECHNICAL DETAILS :
LEAF 2 | XS | S | M | M-L | L |
---|---|---|---|---|---|
Cells | 49 | 49 | 49 | 49 | 49 |
Flat surface area (m²) | 21,2 | 24,4 | 26,2 | 28,6 | 30,4 |
Span (m) | 10,6 | 11,4 | 11,8 | 12,3 | 12,7 |
Chord (m) | 2,49 | 2,67 | 2,76 | 2,89 | 2,97 |
Flat aspect ratio | 5.3 | 5.3 | 5.3 | 5.3 | 5.3 |
Projected surface area (m²) | 17,7 | 20,4 | 21,9 | 24 | 25,5 |
Projected span (m) | 8,2 | 8,8 | 9,1 | 9,5 | 9,8 |
Projected aspect ratio | 3,79 | 3,79 | 3,79 | 3,79 | 3,79 |
Weight (kg) | 4,5 | 4,8 | 5 | 5,2 | 5,4 |
Flying weight range (kg) | 55-75 | 70-90 | 80-100 | 90-110 | 105-125 |
Certification | EN – LTF B | EN – LTF B | EN – LTF B | EN – LTF B | EN – LTF B |
Risers | 3+1 | 3+1 | 3+1 | 3+1 | 3+1 |
CHARACTERISTICS :
Piloting
Autonomous pilots
Foot launch and towing ready
Equipment
Thin risers with extended base
Babysharknose
Ronstan low-friction pulley
Anti-friction rings
Smart mini-ribs
Big-ears kit
Wingtip cleaning system
Materials
Extrados fabric: Porcher Sport Skytex 38 g / m²
Intrados fabric: Porcher Sport Skytex 32 g / m²
Wall fabric: MJ Tec 32 gr Hard finish
Partition reinforcements: Porcher Sport SR 170
High & Intermediate lines: Liros
Low lines: Edelrid
Certification
EN 926 – 1 et 2 et LTF 91/09 Norm – Class B
PRODUCT MAKE-UP :
- LEAF 2 glider
- Backapck Trek130
- Inner bag
- Rolling bag
- Speedbar
- User’s manual (USB stick)
- Repair kit
